RF-A8

RF-A8

技术参数

Technical Parameter


型号 ModelRF-A8
电压 VoltageAC-220V 50HZ
功率 Power2500W
热风温度 Heat ControlUp to 700°C
速度 Speed1-18m/min
压缩空气 Pressrue0.35-0.5M
压轮宽度 Roller width30mm
适用胶带宽度 Applied Tape Width14-25mm
上压轮行程 Upper roller lift20-35mm
机器尺寸 Dimension1300*700*1600mm
净重 Net weight175kg


RF-A8特点:


1.超大操作空间,台板可拆卸,更合适大型帐篷,雨罩等产品加工


2.采用PLC可编程,触摸式数字显示


3.温度自动控制,稳定性能高,温度上限报警设计,保护发热丝


4.自动补偿虚位,自动微退,减少压带空白


5.双脚踏控制,操作舒适,适宜长时间损作


6.可连续24小时工作


7.独特发热管结构,进风经过滤,绝无水分和油分


8.自动剪带、送待,自动带尾完成,减少材料损耗


Featuresof RF-A8


1.Bigger operation space and removable working table make it better for bigger tent,waterproof covers etc


2.Editable PLC control,touch screen display


3.Auto temperature control with warning device for the up limit temperature


4.Auto compensation and reverse5.Double pedals control


6.It could work up to 24 hours


7.Blowing-in hot air is filtrated without any water and oil


8.Auto tape clipping ,feeding and finishing reduce function
