技术参数 Technical Parameter | |
型号 Model | RF-A10 |
电压 Voltage | AC-220V 50HZ |
功率 Power | 2500W |
热风温度 Heat Control | Up to 700°C for hot wedge |
速度 Speed | 1-24m/min |
压缩空气 Pressrue | 0.35-0.5M |
压轮宽度 Roller width | 30mm |
适用胶带宽度 Applicable tape width | 14-25mm |
机器尺寸 Dimension | 1300*600*1550mm |
净重 Net weight | 200kg |
RF-A10特点:
1,适用于各种防水衣物,如防水夹克,雨衣,帐篷,车罩等
2,采用PLC可编程,触摸式数字显示
3,温度自动控制,稳定性能高,温度上限报警设计,保护发热丝
4,自动补偿虚位,自动微退,减少压带空白
5,双脚踏控制,操作舒适,适宜长时间操作
6,可连续24小时工作
7,独特发热管结构,进风经过滤,绝无水分和油分
8,自动剪带,送待,自动带尾完成,减少材料损耗
9,独特双下柱设计,Model1和Model2自由切换,更适宜如桶形状,袖口状产品的封口
Features of RF-A10
1.Suitable for kinds of waterproof garment and products,such as waterproof jacket,raincoat,tent,car cover etc
2.Editable PLC control.touch screen display
3.Auto temperature control with warning device for the up limit temperature
4.Auto compensation and reverse
5.Double pedals control
6.It could work up to 24 hours
7.Blowing- in hot air is filtrated without any water andoil
8. Auto tape cipping, feeding and fnishing reduce fuction
9.Double arms design.Model 1 and Model 2 could be switched freely when you seal different barrel sharp and cuff sharp products
