Details
RF-A2S is special for waterproof shoes and waterproof gloves seam sealing.
技术参数 Technical Parameter | |
型号 Model | RF-A2S |
电压 Voltage | AC-220V 50-60HZ |
功率 Power | 2500W |
热风温度 Heat Control | Up to 700°C |
速度 Speed | 1-24m/min |
压缩空气 Pressrue | 0.35-0.5M |
压轮宽度 Roller width | 25.4mm |
上压轮行程 Upper roller lift | 20-35mm |
机器尺寸 Dimension | 1300*600*1600mm |
净重 Net weight | 160kg |
RF-A2S特点:
1.适用于各类防水鞋的热风封口
2.松下PLC控制
3.上下压轮链条同步传动,自动补偿虚位,自动微退,减少压带空白
4.双脚踏控制,操作舒适,适宜长时间操作
5.可连续24小时工作
6.独特发热管结构,进风经过滤,绝无水分和油分
7.自动剪带、送待,自动带尾完成,减少材料损耗
8.下柱独特超薄设计,适宜各种大小件产品密封压带
Featuresof RF-A2S
1.Special design for waterproof shoe seam sealing
2.Panasonice PLC control
3.The up and low roller chain are synchronous,auto compensation and reverse
4.Double pedals control
5.It could work up to 24 hours
6.Blowing -in hot air is filtrated without any water and oil
7.Auto tape clipping ,feeding and finishing reduce function
8.Supper-thin lower column design,suitable for sealing various sizes products
